SPECS
| Handhelds | Screen Size | 2.8" color TFT, 320*240 Pixels |
| Touch Screen | capacitive touch screen | |
| SD card storage | Yes(8~32G) | |
| Waypoints Number | 100 | |
| Battery | 2*14650 lithium battery (not included) | |
| Charger Port | USB type-c / DC5V 1A | |
| Battery life | 8hr (with 1200mAH 14650 battery) | |
|
BCS-BOX (Boat Control System) |
Signal Interface | PWM,PPM,Uart(optional) |
| Channels of Receiver | 8 | |
| GNSS/Compass Port | RS232, 19200bps | |
| Failing-safe | YES (automatically return to HOME point after signal lost lasting 20s) | |
| Power Input | DC 3.5/1.35mm DC6~16V/200mA | |
| Others | GNSS | GPS, BeiDou, Galileo, GLONASS |
| Radio frequency | 2.4GHz FHSS | |
| Radio Power | 20dBm (500m RC distance , Depends on usage environment) | |
| Compass at Boat Side | Yes | |
| Compass in Handhelds | No | |
| Case size | 179*62*27mm | |
| Waterproof | IP3 waterproof(safe from vertical splashing) |
